UNDERSTANDING ZONING

User Manual (PDF file)
Installation Manual(PDF file)

Installation features and functions

  • Wiring Centre Controller (WC Controller)
    • controls 8 zones and 16 actuators
    • Relays for Pump Circulation and Transformer
    • Separate fuses for 230v ac and Actuators 24vac
    • Temperature sensors either Analog NTC or digital ds18b20;
      • DS18b20 sensors, connects via RJ45, Hub PCB connects 8 sensors with only two cables to the WC Board
      • or NTC10k temperature sensor has a plugin PCB onto the WC board
    • All wires to the WC controller use pluggable connections, removing and testing becomes much quicker and simpler.
    • Two relays for the Heat source so can do standard heating for all types of boilers and cooling as well if a heat pump.
    • All 12 relays have an LED to indicate if its “on”, a simple visual inspection can see exactly what should be operating.
    • Clear lid to see the status all relays and the micro controller, if powered Red LED and connected to the LAN Green Led
    • No limit to the number of WC Controllers installed.
    • Flow sensors and pressure sensors.
  • Easy to remotely identify system faults.
  • No limit to the number of WC boards installed for the home, one to 100 rooms or more. (8 Zones per board with no limit to temp sensors).
  • Allocate any temperature sensor to any thermostat.
  • One thermostat can control multiple thermostats, Master and Slave.
